Complete repair guide for the Fleetwood Bounder – Furnace Igniter & Control Board Replacement. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Suburban RP-35Q 35,000 BTU/h RV Replacement Core for Suburban Furnace Series SF-35, SF-35Q, SF-42, SF-42Q, and SF-Q (2609A) — Suburban/Atwood RV furnace (replacement unit)
- Fit For Suburban RV Furnace Parts 232286,Single Probe Gas Furnace Igniters Electrode with Wire Assembly, Camper Furnace For Suburban 232286 Above 934701426 SF-20, SF-25, SF-30, SF-35 (SF Series) — Furnace igniter electrode
- DTAIR 33082 Sail Switch Replacement for Select Dometic Atwood RV Furnace(Pack of 2) — Furnace sail switch
- 520814 Rv Water Heater Module Board Ignition Control Circuit Board Compatible with Suburban Furnace SW4D, SW6D, SW6DE, SW12D, SW6DEM RV Water Heaters,Replace 520814 520820 520871 33550L (With lid) — Furnace circuit board / control board
- DTAIR 33082 Sail Switch Replacement for Select Dometic Atwood RV Furnace(Pack of 2) — Furnace high-limit switch
- Suburban 232684 RV Furnace 12v SF-Series DC Blower Motor, SF-35, SF-35F, SVF-35, SF-42, SF-42F OEM Caliber — Furnace blower motor (12V DC)
- RV Carbon Monoxide & Propane Gas Alarm, Briidea Dual LP/CO Detector with Separate LED Indicator Light, 100dB Loud Alarm, 12 VDC, Black — Propane/CO combo detector alarm
- FKM Pro Digital Multimeter Tester TRMS 6000 Counts,Smart Rechargeable Voltmeter 5″Color LCD,Auto-Ranging Automotive Multimeters,for AC/DC Current/Voltage,NCV,Ohm,Capacitance,Resistance,Continuity,Temp — Digital multimeter
Step 1: Diagnose Furnace Issues and Prepare Workspace
Start by testing your furnace to identify whether the problem stems from the igniter electrode or control board. Turn on the furnace and listen for the blower motor activation—if you hear clicking but no ignition, the igniter electrode is likely faulty. If there’s no response at all, the circuit board may be dead. Before beginning work, disconnect the negative battery terminal to cut all 12V DC power, then allow the furnace to cool for at least 30 minutes. Gather your tools, parts, and a digital multimeter in a well-lit workspace near your furnace compartment.
Step 2: Access and Remove the Furnace Access Panel
Locate your Fleetwood Bounder’s furnace access panel, typically found in a basement cabinet or under a dinette seat. Remove the panel by unbolting the 3-4 fasteners (usually ¼-inch bolts) that secure it, then carefully slide the panel out and set it aside. Take a photo of the furnace’s wiring configuration with your phone before disconnecting anything—you’ll reference this during reassembly. This gives you clear access to the igniter electrode, sail switch, and circuit board without removing the entire furnace unit.
Step 3: Disconnect Electrical Connectors and Document Wiring
Identify and carefully disconnect all electrical connectors from the furnace circuit board, including the 12V DC power harness, blower motor leads, and igniter electrode connector. Use your multimeter to verify that power is truly disconnected by testing across the main power terminals—you should read 0V DC. Draw a simple wiring diagram or use your phone to photograph each connector before removal, noting the wire colors and connector positions. This documentation is critical for reassembly, as incorrect connections can prevent ignition or damage the new control board.
Step 4: Remove Old Igniter Electrode and Control Board
Unbolt the furnace igniter electrode from its mounting bracket—typically secured with a single 10mm bolt or setscrew. Gently pull the electrode straight out and inspect the ceramic insulator for cracks or discoloration, which confirms it needs replacement. Next, unbolt the furnace circuit board (usually 2-3 fasteners) and slide it out of its mounting location. Inspect the board’s surface for burnt components, corrosion, or water damage; any of these indicates the board requires replacement.
Step 5: Install New Control Board and Igniter Electrode
Slide the new furnace circuit board into its mounting position and secure it with the original bolts, tightening to finger-tight plus one-quarter turn—over-torquing can crack the board. Install the new furnace igniter electrode into its mounting bracket, ensuring the ceramic insulator is fully seated and the electrode tip is properly aligned (typically 3-4mm gap from the burner). Check that the electrode doesn’t contact any metal surfaces, as this will prevent ignition. Reconnect all electrical harnesses to the circuit board first, then attach the igniter electrode connector last, following your wiring photograph.
Step 6: Reconnect All Systems and Verify Sail Switch Function
Reconnect the negative battery terminal and restore 12V DC power to the furnace. Manually inspect and operate the furnace sail switch (the hinged flapper that detects airflow) to ensure it moves freely without sticking—gently bend it back and forth by hand. Check that all wire connectors are fully seated by tugging gently on each one; a loose connector is the leading cause of intermittent furnace failures. Verify that the blower motor spins freely by rotating the fan blade by hand (power should still be off for this check).
Step 7: Test Furnace Operation and Monitor for Proper Function
Turn on the furnace and listen for the sequence: blower activation (5-10 seconds of pre-purge), igniter clicking (typically 10-15 seconds), and then a soft whoosh as the burner ignites. The burner flame should be blue with minimal yellow tips and should remain steady without flickering. Let the furnace run for at least 10 minutes, monitoring the cabinet temperature to ensure the high-limit switch allows normal operation. Finally, test your Propane/CO combo detector alarm by pressing its test button—it should sound within 3 seconds, confirming your safety systems are operational.
