Holiday Rambler Navigator – Furnace Igniter & Control Board Replacement

Holiday Rambler Navigator – Furnace Igniter & Control Board Replacement

by

Complete repair guide for the Holiday Rambler Navigator – Furnace Igniter & Control Board Replacement. Follow these steps to diagnose and fix the issue yourself.

Parts & Tools You’ll Need

Step 1: Diagnose Furnace Ignition Failure

Start by locating your Holiday Rambler Navigator’s furnace unit, typically mounted in the basement or storage compartment. Use your digital multimeter to test for 12V DC power at the control board connector while the thermostat calls for heat—no voltage indicates a board failure, while voltage without ignition suggests a faulty igniter electrode. Listen for the sail switch click when the blower activates; if absent, the sail switch may need replacement before proceeding.

Step 2: Shut Down Power and Propane Supply

Turn off the 12V DC circuit breaker controlling your furnace system and close the propane isolation valve located upstream of the furnace regulator. Wait at least 5 minutes to allow any residual propane to dissipate, then verify no gas odor is present near the furnace compartment. This step is critical—never work on a live furnace system or with propane actively flowing.

Step 3: Remove Old Control Board Assembly

Disconnect the 4-pin Molex connector from the existing circuit board, noting the wire color sequence (typically red/black/yellow/white) for reference. Unbolt the control board from its mounting bracket using a Phillips screwdriver—there are usually 2-3 fasteners. Carefully slide out the old board and set it aside; the new Suburban/Atwood replacement board uses the same mounting footprint and connector type.

Step 4: Install New Furnace Circuit Board

Position your replacement circuit board into the mounting bracket and secure with the original fasteners, tightening to finger-tight plus a quarter turn to avoid cracking the PCB. Reconnect the 4-pin Molex connector, matching the wire colors to their original positions—reversing polarity will damage the new board immediately. Double-check that the connector is fully seated by gently tugging on the harness.

Step 5: Replace Furnace Igniter Electrode

Locate the ceramic igniter electrode mounted inside the burner box, typically held by a single Phillips screw or push-pin fastener. Disconnect the spade terminal connector from the electrode’s lead wire and carefully remove the old unit. Install the new furnace igniter electrode in the identical position, ensuring the ceramic tip points directly at the propane burner orifice and is spaced 1/4 inch from the flame path.

Step 6: Verify Sail Switch and High-Limit Safety

Inspect the furnace sail switch for bent or corroded contacts—if damaged, install the replacement sail switch which uses the same snap-fit mounting bracket. Test the high-limit switch by gently pressing the reset button; if it doesn’t click, replace it using the same procedure. Both safety switches must function properly or the control board will not allow ignition, so verify each switch moves freely and returns to its original position.

Step 7: Test System and Verify Safe Operation

Restore power to the 12V circuit breaker and open the propane isolation valve, then set your thermostat 5 degrees above the current cabin temperature to call for heat. Listen for the blower motor to activate within 30 seconds, followed by the igniter sparking for approximately 15 seconds and propane igniting with a soft whoosh sound. Use your Propane/CO combo detector alarm to confirm no gas leaks near the furnace connections, and allow the furnace to run for 10 minutes while monitoring that warm air flows from all vents—if ignition fails or the high-limit switch trips repeatedly, shut everything down and recheck your control board connections.
