Complete repair guide for the Jayco Melbourne – Diesel Heater Glow Plug & Fuel Pump Service. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Webasto / Espar ceramic glow plug
- Diesel heater fuel dosing pump (12V)
- Inline diesel fuel filter
- Diesel heater LCD control panel
- Combustion chamber blower motor
- Intake & exhaust silencer kit
- Diesel fuel line silicone tubing (4mm)
- Digital multimeter (auto-ranging)
Disclosure: This post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.
Step-by-Step Repair Guide
Step 1: Diagnose Heater Issues & Prepare
Start by checking your diesel heater’s performance using your digital multimeter to test voltage at the glow plug connector and fuel pump terminals. Disconnect the negative battery terminal and allow the system to cool completely before proceeding with any component removal.
Step 2: Remove Old Glow Plug Assembly
Locate the ceramic glow plug in the combustion chamber and carefully unscrew it using the appropriate socket, being cautious not to damage the delicate heating element. Clean any debris or carbon buildup from the glow plug chamber before installing your replacement component.
Step 3: Replace Diesel Fuel Dosing Pump
Disconnect the fuel lines from your existing 12V fuel dosing pump and unscrew the mounting bracket from the heater body. Install your new fuel dosing pump by reversing the removal process, ensuring all connections are tight and the fuel flow direction matches the arrow marking on the pump housing.
Step 4: Install New Inline Fuel Filter
Cut and remove the old diesel fuel filter from the fuel line, then insert your new inline filter with the arrow pointing toward the heater unit. Use fresh 4mm silicone tubing to reconnect the fuel lines, ensuring no kinks or restrictions that could impede fuel flow to the dosing pump.
Step 5: Update LCD Control Panel Settings
Reconnect your battery and power on the new LCD control panel, then navigate to the heater settings menu to configure fuel type and heating intensity preferences. Verify that all display segments illuminate and the panel responds correctly to your button inputs before proceeding to the blower motor installation.
Step 6: Install Blower Motor & Silencers
Mount the combustion chamber blower motor in its original location and secure the intake and exhaust silencer kit components to reduce operational noise. Connect the blower motor’s electrical harness to the main heater control unit, ensuring the silicers are properly sealed to prevent exhaust leaks.
Step 7: Test Complete System Operation
Reconnect your negative battery terminal and activate the heater through the LCD panel, allowing it to run through a full startup cycle while monitoring glow plug voltage and fuel pump operation with your multimeter. Listen for normal combustion sounds and verify that exhaust flows smoothly through the silencer before declaring the service complete.
