Complete repair guide for the Keystone Alpine – Furnace Igniter & Control Board Replacement. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Suburban/Atwood RV furnace replacement unit
- Furnace igniter electrode assembly
- Furnace sail switch
- Furnace circuit board / control board
- Furnace high-limit switch
- Furnace blower motor (12V DC)
- Propane/CO combo detector alarm
- Digital multimeter (auto-ranging)
Disclosure: This post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.
Step-by-Step Repair Guide
Step 1: Diagnose Furnace Ignition Failure
Start by turning on your furnace and listening for the characteristic clicking sound of the igniter electrode attempting to spark. If you hear no clicking or the furnace won’t ignite after several attempts, use your digital multimeter set to voltage mode to test the 12V DC power supply reaching the control board, checking both positive and negative terminals.
Step 2: Disconnect Power and Propane
Turn off the furnace at the thermostat and flip the main RV electrical breaker to kill all power to the system. Locate your propane shut-off valve and turn it to the closed position, then wait 5 minutes to allow any residual gas to dissipate before proceeding with removal.
Step 3: Remove Furnace Access Panel
Locate the furnace access panel, typically found in a lower cabinet or basement area beneath your RV, and remove all fasteners using appropriate wrenches or screwdrivers. Take a photo or video of the existing wire connections to the control board before disconnecting anything, as this documentation will be invaluable during reassembly.
Step 4: Extract Old Igniter Electrode
Locate the furnace igniter electrode assembly inside the combustion chamber area and carefully disconnect its wiring harness from the control board. Remove any mounting brackets or clips holding the electrode in place, then gently slide it out of its position without forcing it or damaging surrounding components.
Step 5: Install New Control Board Assembly
Position the new furnace circuit board in the exact location of the old board, aligning all mounting holes with the existing brackets. Reconnect all wiring harnesses to their corresponding terminals, following your reference photo or the new board’s wiring diagram to ensure correct polarity and connections.
Step 6: Connect Fresh Igniter Electrode
Insert the new furnace igniter electrode assembly into its mounting location within the combustion chamber, ensuring it sits flush and secure. Attach the electrode’s wiring harness to the designated terminals on your new control board, verifying the connection is tight and fully seated.
Step 7: Test Complete Furnace Operation
Restore propane flow and electrical power, then activate your furnace and listen for the igniter spark click within 10-15 seconds of startup. Use your digital multimeter to verify proper voltage at the igniter electrode terminals, and confirm the furnace reaches full heating capacity while monitoring for any propane/CO detector alerts.
