KEYSTONE BULLET 287QBS – Furnace Igniter Replacement

by

Complete repair guide for the KEYSTONE BULLET 287QBS – Furnace Igniter Replacement.

Parts & Tools You’ll Need

Step 1: Diagnose Furnace Ignition System Failure

Start by disconnecting the negative battery terminal to ensure safety while diagnosing the system. Listen for the blower motor activation when you turn on the thermostat—if you hear the motor but smell no gas ignition attempt, you likely have a bad igniter or control board. Check for error codes on your digital thermostat display and visually inspect the furnace compartment for any visible damage, corrosion, or loose connections around the igniter electrode and control board. Document your findings before proceeding to determine whether you need to replace just the igniter, the entire control board, or both components.

Step 2: Remove Furnace Access Panel and Components

Locate the furnace access panel on the Keystone Bullet 287QBS, typically found in the basement cabinet area, and remove the retaining screws (usually 3-4 Phillips head fasteners). Carefully slide out the control board assembly and take a photo of the wire connections before disconnecting them—label each wire with masking tape if the connectors aren’t color-coded. Note the position of the Furnace Spark Electrode Igniter and document its mounting orientation, as reinstallation accuracy is critical for proper ignition. Set all removed components on a clean, static-free work surface and keep fasteners organized in a small container.

Step 3: Disconnect and Replace Control Board

Identify which control board your unit uses (Suburban SF-35 or Atwood RV Furnace Circuit Board, as both are compatible with this model) and disconnect the wire harness by gently prying the connector clip with a small flathead screwdriver. Remove the mounting bracket bolts securing the old board (typically 2-3 bolts torqued to 4-6 inch-pounds) and slide the board away from the furnace housing. Install the new replacement board by first securing the mounting bracket with the same fasteners at the same torque specification, then carefully align and reconnect the wire harness, ensuring each connector seats fully until you hear a click. Double-check that no wires are pinched or routed near heat sources.

Step 4: Install New Furnace Spark Electrode Igniter

Remove the old Furnace Spark Electrode Igniter by unbolting the ceramic mounting block (usually 1-2 small bolts at 2-4 inch-pounds) and disconnecting the igniter wire from the control board terminal. Clean the igniter mounting area inside the furnace combustion chamber with a soft brush to remove any carbon deposits or debris that could affect electrode spacing. Carefully install the new Furnace Spark Electrode Igniter with the electrode tip positioned approximately 3/16 inch (4.8mm) from the burner tube opening—use a feeler gauge to verify this critical clearance. Reconnect the igniter wire and torque the mounting bolts to 2-4 inch-pounds, being careful not to over-tighten and crack the ceramic insulator.

Step 5: Test and Replace Sail Switch if Needed

Locate the RV Furnace Sail Switch, a small paddle-like component in the blower outlet duct that detects airflow, and inspect it for debris or corrosion. Gently move the sail arm by hand to confirm it pivots freely; if it sticks or shows visible damage, you’ll need to replace it with a new RV Furnace Sail Switch Replacement unit. To replace, disconnect the switch’s wire connector and remove the mounting bracket bolts (typically 2 bolts at 3-5 inch-pounds), then install the new switch with the sail paddle oriented perpendicular to the airflow path. Reconnect the wire harness and verify the sail moves freely without binding.

Step 6: Reassemble Furnace and Restore Power Connection

Carefully slide the reassembled furnace assembly back into its cabinet position, ensuring all wires remain properly routed and no connections have shifted during reinstallation. Reinstall the furnace access panel by aligning the mounting holes and inserting the retaining screws, torquing them snugly (approximately 8-12 inch-pounds) without over-tightening and stripping the plastic threads. Reconnect the negative battery terminal and verify that the thermostat powers on and displays the current mode setting. Check that no warning lights or error codes appear on the digital thermostat display—any codes should be documented for Step 7 testing.

Step 7: Perform Complete Furnace System Test Cycle

Set the thermostat to heating mode and adjust the temperature setpoint 5 degrees above the current cabin temperature to trigger a furnace startup cycle. Listen for the blower motor to activate within 10 seconds, followed by an audible ignition spark (a rapid clicking sound) and then the smell of gas ignition within 3-5 seconds of the spark starting. Allow the furnace to run for at least 10 minutes and confirm that warm air flows consistently from all cabin vents without interruption or flame rollout. Once satisfied with normal operation, return the thermostat to its normal setpoint and monitor the furnace during at least two complete heating cycles over the next 24 hours to ensure reliable, repeatable ignition performance.
