Complete repair guide for the Newmar Dutch Star – AC Capacitor & Fan Motor Service. Follow these steps to diagnose and fix the issue yourself.

Parts & Tools You’ll Need

Step 1: Diagnose AC System & Disconnect Power

Begin by switching off the RV’s main electrical panel and the dedicated 30-amp breaker serving the rooftop AC unit to eliminate shock hazard. Listen for audible humming or buzzing from the AC compressor compartment—a weak hum or complete silence often indicates a failed capacitor, while grinding noises suggest fan motor bearing wear. Use your non-contact infrared thermometer to measure the temperature differential between the condenser outlet and indoor return air (you should see a 15–20°F drop); a minimal difference confirms reduced cooling capacity.

Step 2: Remove Shroud & Access Internal Components

Climb onto your Dutch Star’s roof and locate the four corner bolts securing the rooftop AC shroud/outer cover; remove these 3/8-inch fasteners with a socket wrench and set them aside in a labeled container. Carefully lift the aluminum shroud straight upward to avoid snagging internal wiring or refrigerant lines, then set it on a blanket to prevent damage to the finish. Document the positions of any wires or hoses with photos before proceeding, as this serves as your reassembly reference.

Step 3: Inspect & Replace Dual Run Capacitor

Locate the cylindrical capacitor (typically rated 40+5 µF, 440V for Dometic or Coleman-Mach units) mounted near the fan motor on a bracket. Before touching it, use an insulated screwdriver to short the two terminals together to safely discharge any residual voltage, then disconnect the wire terminals using a 1/4-inch socket. Install the new RV AC dual run capacitor by reversing this process—ensure the polarity matches (check the label for Common, Herm, and Fan terminals) and use crimp connectors rated for 440V, tightening them snugly without over-crimping.

Step 4: Remove & Test Fan Motor Assembly

Disconnect the three-pin motor connector from the control board and unbolt the fan motor from its mounting plate (typically four 1/4-inch bolts arranged in a square pattern). Manually rotate the motor shaft—it should spin freely with minimal resistance; if it’s grinding, stiff, or locked, bearing failure has occurred and replacement is necessary. Before installing a new motor, verify that the mounting bracket is straight and the motor pulley aligns with the fan blade centerline to ±1/8 inch.

Step 5: Clean Evaporator & Condenser Coils

Spray the AC evaporator/condenser coil cleaner foam directly onto both the indoor and outdoor coil surfaces, working from top to bottom to prevent cleaner from pooling. Allow the foam to sit for 10–15 minutes to break down mineral deposits and biological growth, then rinse thoroughly with a soft-bristle brush and distilled water (tap water leaves mineral residue). Use your fin comb/coil straightener tool to carefully straighten any bent aluminum fins, working gently to avoid puncturing the tubing—bent fins reduce airflow efficiency by up to 30%.

Step 6: Reinstall Shroud & Reseal Roof Gasket

Position the rooftop AC shroud back onto the mounting surface and insert the four corner bolts, tightening them in a criss-cross pattern (top-left, bottom-right, top-right, bottom-left) to ensure even pressure and prevent gasket compression asymmetry. Apply a continuous bead of AC roof gasket & self-leveling sealant around the entire perimeter where the shroud meets the roof (typically ½-inch wide bead), then allow the sealant to cure for 24 hours before testing. Check that the gasket has self-leveled evenly and there are no voids or gaps larger than 1/16 inch.

Step 7: Power-On Test & Verify Cooling Performance

Restore power at the main panel and the 30-amp breaker, then set the RV thermostat/control board to COOL mode at 72°F to initiate a full-cycle test. Listen for smooth fan motor operation (no grinding or buzzing) and measure the supply air temperature at the interior vent opening using your infrared thermometer—it should drop to 50–58°F within 5 minutes, indicating proper capacitor and motor function. After running for 15 minutes, verify that the outdoor condenser is expelling warm air, the refrigerant lines show appropriate temperature differential, and no refrigerant oil residue appears around connection points.
