Complete repair guide for the Thor Dazzle – Diesel Heater Glow Plug & Fuel Pump Service. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Webasto / Espar ceramic glow plug
- Diesel heater fuel dosing pump (12V)
- Inline diesel fuel filter
- Diesel heater LCD control panel
- Combustion chamber blower motor
- Intake & exhaust silencer kit
- Diesel fuel line silicone tubing (4mm)
- Digital multimeter (auto-ranging)
Disclosure: This post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.
Step-by-Step Repair Guide
Step 1: Diagnose Heater Issues Safely
Start by disconnecting your battery’s negative terminal to ensure electrical safety while working on the diesel heater system. Use your digital multimeter to test the glow plug’s resistance and the fuel pump’s voltage output, noting any readings below manufacturer specifications that indicate failure.
Step 2: Remove Old Glow Plug
Locate the ceramic glow plug in the heater’s combustion chamber and carefully unscrew it using the appropriate socket, taking care not to damage the heating element. Once removed, inspect the combustion chamber for carbon buildup and debris, cleaning it gently with a soft brush if necessary.
Step 3: Replace Fuel Dosing Pump
Disconnect the fuel lines from the old 12V fuel dosing pump by carefully loosening the compression fittings and capturing any residual diesel in a container. Install your new fuel pump in the same orientation, ensuring secure connections and proper alignment with the fuel intake line before proceeding.
Step 4: Service Fuel Filter System
Replace the inline diesel fuel filter by disconnecting both the supply and return lines, then position your new filter in the same location with the arrow pointing toward the heater unit. Prime the new filter by hand-pumping the fuel system several times to remove air pockets before starting diagnostics.
Step 5: Inspect Silencer Components
Remove both the intake and exhaust silencers from your diesel heater assembly by unbolting the mounting hardware and disconnecting the associated ducting. Replace any damaged silencers with your new intake and exhaust silencer kit, ensuring all connections are airtight to prevent performance loss.
Step 6: Update Control Panel Settings
If you’ve installed a new LCD control panel, connect it to the heater’s main control module following the wiring diagram specific to your Webasto or Espar unit. Program the desired temperature setpoint and heating schedule through the panel’s menu system, then verify all settings have been saved properly.
Step 7: Test Complete System Operation
Reconnect the battery’s negative terminal and power on your diesel heater, monitoring the LCD panel for proper startup sequence and flame ignition within 30 seconds. Use your multimeter to verify that the glow plug reaches operating temperature and that the fuel pump pressure stabilizes between 0.5 and 1.5 bar during continuous operation.
