Complete repair guide for the Thor Sequence – Diesel Heater Glow Plug & Fuel Pump Service. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Webasto / Espar ceramic glow plug
- Diesel heater fuel dosing pump (12V)
- Inline diesel fuel filter
- Diesel heater LCD control panel
- Combustion chamber blower motor
- Intake & exhaust silencer kit
- Diesel fuel line silicone tubing (4mm)
- Digital multimeter (auto-ranging)
Disclosure: This post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.
Step-by-Step Repair Guide
Step 1: Diagnose Heater Failure Symptoms
Start by connecting your digital multimeter to the heater’s 12V power supply and verify voltage is reaching the control panel—low or absent voltage indicates electrical issues rather than component failure. Listen for the combustion chamber blower motor running when you activate the heater; if there’s no sound or weak operation, the glow plug or fuel pump may be faulty. Check the LCD control panel for error codes or warning lights that pinpoint whether the issue stems from ignition failure, fuel delivery problems, or motor malfunction.
Step 2: Disconnect Battery and Access Heater
Disconnect the negative battery terminal to prevent electrical shorts or accidental activation during service, then locate your diesel heater unit—typically mounted in the engine bay or under cabinetry depending on your Thor Sequence model. Remove any protective covers, ducting, or access panels to expose the glow plug assembly and fuel pump connections. Take photos of the wiring harness configuration before disconnecting anything to ensure accurate reassembly later.
Step 3: Remove Fuel Lines and Glow Plug
Carefully disconnect the 4mm silicone diesel fuel tubing from the heater inlet, keeping the open ends elevated to prevent fuel spillage and contamination. Unscrew the ceramic glow plug from the combustion chamber using the appropriate socket, noting its orientation and the condition of the sealing gasket. Inspect the old glow plug for carbon buildup or corrosion—heavy buildup suggests fuel pump timing or combustion issues requiring further investigation.
Step 4: Replace Fuel Dosing Pump Assembly
Disconnect the fuel dosing pump’s electrical connector and mounting bolts, then carefully remove the pump from its bracket while supporting the fuel line connections. Install the new 12V diesel heater fuel dosing pump in the same orientation, ensuring the intake port faces the fuel filter direction and the outlet connects properly to the heater inlet. Reconnect the electrical harness and tighten all mounting bolts to secure the pump against vibration.
Step 5: Install New Glow Plug and Filter
Thread the new ceramic Webasto/Espar glow plug into the combustion chamber by hand first, then carefully tighten using your socket to avoid cross-threading or damaging the heating element. Replace the inline diesel fuel filter with a fresh unit, ensuring the flow direction arrow points toward the heater inlet. Reconnect all 4mm silicone fuel tubing, double-checking that each connection is hand-tight and secure against potential leaks.
Step 6: Verify Combustion System Operation
Reconnect the battery negative terminal and activate the heater control panel, observing the LCD display for proper startup sequence and error code absence. Listen for the combustion chamber blower motor starting smoothly and the characteristic ignition click as the glow plug energizes—these indicate successful electrical connections. If the blower runs but you hear no ignition spark, the glow plug may still be defective or the fuel pump timing may need adjustment via the control panel menu.
Step 7: Test Heat Output and System Stability
Allow the heater to run for 10–15 minutes at full output, checking for steady warm airflow from all vents and verifying the LCD panel shows stable operation temperature around 60–70°C. Position your multimeter to measure the glow plug voltage during ignition—you should see approximately 12V for 3–5 seconds during the startup cycle. Inspect all fuel line connections and the pump area for leaks, then shut down the heater and let it cool before returning covers and ducting to their original positions.
