Complete repair guide for the Winnebago Revel 44E – Diesel Heater Glow Plug & Fuel Pump Service. Follow these steps to diagnose and fix the issue yourself.
Parts & Tools You’ll Need
- Webasto / Espar ceramic glow plug
- Diesel heater fuel dosing pump (12V)
- Inline diesel fuel filter
- Diesel heater LCD control panel
- Combustion chamber blower motor
- Intake & exhaust silencer kit
- Diesel fuel line silicone tubing (4mm)
- Digital multimeter (auto-ranging)
Disclosure: This post contains affiliate links. We may earn a commission on qualifying purchases at no extra cost to you.
Step-by-Step Repair Guide
Step 1: Diagnose Heater Malfunction Safely
Start by checking your LCD control panel for error codes, which will indicate whether you’re dealing with a glow plug or fuel pump issue. Disconnect the negative battery terminal and allow the system to depressurize for at least 15 minutes before proceeding with any repairs to ensure your safety.
Step 2: Access Diesel Heater Components
Locate your Webasto or Espar diesel heater unit, typically mounted in the engine bay or under the chassis of your Winnebago Revel 44E. Remove the protective cover panels and disconnect the fuel lines and electrical connectors to expose the glow plug and fuel dosing pump assembly.
Step 3: Replace Ceramic Glow Plug
Unscrew the faulty ceramic glow plug from the combustion chamber using a socket wrench, then install the new glow plug with hand-tight pressure followed by a quarter-turn to ensure proper seating. Use your digital multimeter to test the new glow plug’s resistance before fully reassembling to confirm it’s functioning correctly.
Step 4: Install New Fuel Dosing Pump
Remove the old 12V fuel dosing pump by disconnecting its electrical connector and unbolting it from the heater housing. Position the new pump in the same orientation, secure it with bolts, and reconnect the electrical wiring, ensuring the polarity matches the original configuration.
Step 5: Replace Fuel Lines Completely
Cut away the old diesel fuel line silicone tubing and replace it with new 4mm tubing, ensuring all connections are tight and leak-free. Install the new inline diesel fuel filter in the fuel supply line before the dosing pump to improve heater longevity and performance.
Step 6: Verify Blower Silencer Assembly
Check the intake and exhaust silencer kit components for cracks or carbon buildup, cleaning or replacing them as needed. Reinstall the combustion chamber blower motor and ensure all silencer connections are secure to minimize operational noise and maintain proper airflow.
Step 7: Test System Operation Thoroughly
Reconnect the battery and power on your LCD control panel, allowing the glow plug to cycle through its heating sequence while monitoring for error codes. Run the heater for 10-15 minutes, checking for proper fuel flow, flame ignition, and warm air output before declaring the repair complete.
