Forest River FR3 – AC Capacitor & Fan Motor Service

by

The most expensive mistake RV owners make is replacing parts before they’ve diagnosed the actual problem. I’ve walked up to rigs where the owner has already swapped three components and the real issue is something a five-dollar fuse or a loose connector would have fixed. Diagnosis first. Always diagnosis first. On the Forest River FR3, the rooftop AC unit is one of the first systems to cause grief — and nine times out of ten, what looks like a dead air conditioner is actually a failing run capacitor or a worn-out fan motor, both of which are completely serviceable on-site without pulling the entire unit. Get the diagnosis wrong, swap the wrong part, and you’re out a few hundred dollars and still sweating — so follow this guide closely, work through each step in order, and you’ll know exactly what you’re dealing with before you spend a dime.

Parts & Tools You’ll Need

Step 1: Diagnose AC Failure and Disconnect Power

Start by switching off your RV’s main electrical panel and the dedicated AC breaker to ensure complete power isolation—this is critical for safety when working with capacitors, which store charge even when power is off. Use a multimeter set to AC voltage to confirm zero voltage at the thermostat terminals, then visually inspect the rooftop AC unit for obvious signs of damage, corrosion, or burnt components around the capacitor and fan motor assembly.

Step 2: Remove Rooftop AC Shroud and Access Components

Climb onto your Forest River FR3’s roof and unbolt the four corner fasteners securing the rooftop AC shroud/outer cover using a socket wrench. Carefully lift the shroud away from the AC housing, noting the orientation of any wiring or ducting connections, and set it aside on a clean surface to prevent damage or contamination.

Step 3: Safely Discharge and Replace the Capacitor

Before touching the RV AC dual run capacitor, use an insulated screwdriver to short the two terminal leads together to safely discharge any residual electrical charge. Disconnect the two wire terminals by unbolting them from the capacitor posts, note their positions (typically marked as HERM, FAN, and COM on the capacitor body), and install the new capacitor ensuring the microfarad rating matches your original unit—typically 40+5 µF for Dometic or Coleman-Mach units.

Step 4: Inspect and Clean Coils Before Motor Service

Apply the AC evaporator/condenser coil cleaner foam to all aluminum fins and coil surfaces, allowing it to sit for 5-10 minutes before rinsing thoroughly with low-pressure water from a spray bottle. Use the fin comb/coil straightener tool to gently straighten any bent fins, working perpendicular to the fin direction to restore proper airflow—bent fins reduce cooling efficiency by 10-15%.

Step 5: Remove and Replace the Fan Motor Assembly

Disconnect the fan motor’s electrical connector and unbolt the 4-6 mounting brackets securing the motor to the AC housing using a socket set. Carefully lift the old RV rooftop AC fan motor out of the unit, then position the new motor into the same mounting location, ensuring the mounting feet align with the holes, and secure with grade 5 bolts torqued to approximately 12-15 ft-lbs to avoid over-tightening.

Step 6: Reinstall Shroud and Reseal Roof Penetration

Place the rooftop AC shroud back over the unit, aligning the corner mounting holes, and reinstall the four fasteners hand-tight before fully tightening with a socket wrench. Apply a continuous bead of AC roof gasket & self-leveling sealant around the base perimeter where the shroud meets the roof, allowing it to cure for 24 hours before exposing the unit to water or rain.

Step 7: Test Unit Function and Verify Cooling Performance

Restore power at your RV’s electrical panel and AC breaker, then set the RV AC thermostat/control board to cool mode at 68°F and run the system for 10-15 minutes. Use a non-contact infrared thermometer to measure the temperature of air exiting the AC vents (should be 15-25°F cooler than return air) and verify the fan motor spins smoothly without grinding noise, confirming successful component replacement.
