Complete repair guide for the Newmar Ventana – AC Capacitor & Fan Motor Service. Follow these steps to diagnose and fix the issue yourself.

Parts & Tools You’ll Need

Step 1: Diagnose AC Issues and Prepare Work Area

Start by identifying whether your cooling problem stems from a failed capacitor or fan motor by listening for humming sounds without the fan spinning, or complete AC shutdown. Turn off power at the main breaker and the thermostat, then gather your tools on the roof—you’ll need a non-contact infrared thermometer, multimeter, and safety equipment including gloves and eye protection. Document the current refrigerant pressure reading (typically 65-75 PSI on the low side) and note any visible damage to the rooftop shroud or corrosion around electrical connections.

Step 2: Remove Rooftop AC Shroud and Access Components

Unbolt the RV AC rooftop shroud outer cover using a 10mm wrench, carefully setting aside the four corner bolts and noting their original positions for reinstallation. Gently lift the shroud away from the unit, taking care not to disturb any refrigerant lines or electrical harnesses running beneath it. Inspect the AC roof gasket for cracks, deterioration, or gaps—if the seal is compromised, you’ll need to replace it along with self-leveling sealant to prevent water intrusion.

Step 3: Test and Replace Dual Run Capacitor Unit

Use your multimeter set to capacitance mode to test the RV AC dual run capacitor (typically rated 35/5 µF on most Dometic or Coleman-Mach units); a reading significantly below the marked specification indicates failure. Discharge any residual voltage by using an insulated screwdriver to short the capacitor terminals together, then disconnect the wire spade connectors and remove the mounting bracket bolt. Install the new RV AC dual run capacitor in the same orientation, ensuring all three terminals (common, herm, and fan) are reconnected to their original positions—swap or incorrect connections will prevent the AC from functioning.

Step 4: Inspect and Service Evaporator Coil Assembly

Apply the AC evaporator/condenser coil cleaner foam liberally across the coil fins, allowing it to sit for 10-15 minutes to break down dust and algae buildup that restricts airflow. Use the fin comb/coil straightener tool to gently straighten any bent fins, working in one direction only to avoid further damage—bent fins can reduce cooling efficiency by 15-20%. Rinse thoroughly with low-pressure water and allow to dry completely before reassembly.

Step 5: Remove and Replace Fan Motor Assembly

Disconnect the fan motor electrical harness by depressing the locking tab on the connector, then remove the three mounting bolts securing the RV rooftop AC fan motor to the fan shroud. Lift out the old motor and compare it directly to the new unit to confirm identical dimensions and shaft diameter—most Newmar Ventana units use a 1/4-inch shaft with standard 115V single-phase motors. Install the new RV rooftop AC fan motor in reverse order, ensuring the motor shaft aligns perfectly with the fan blade hub before fully tightening the mounting bolts.

Step 6: Reseal and Reinstall Rooftop AC Shroud

If you removed the AC roof gasket, apply a continuous bead of self-leveling sealant around the entire gasket perimeter and press it firmly into the mounting groove, ensuring no gaps remain. Carefully lower the rooftop AC shroud back into place, aligning the bolt holes and hand-tightening all four corner bolts before using a torque wrench to tighten them to 8-10 foot-pounds in a cross pattern (front-left, rear-right, front-right, rear-left). Double-check that all electrical connectors are fully seated and that no refrigerant lines are pinched or stressed beneath the shroud.

Step 7: Test System Operation and Verify Temperature Output

Restore power at the main breaker and thermostat, then set the AC to cooling mode and allow the system to run for 5 minutes before measuring output temperature using your non-contact infrared thermometer—properly functioning units should deliver air between 55-65°F at the ceiling vent. Listen for smooth fan motor operation with no grinding or unusual noises, and verify that the capacitor is not warm to the touch after 10 minutes of runtime. Check refrigerant pressure again to confirm it matches your pre-service reading; significant deviation (more than ±5 PSI) may indicate a separate refrigerant leak requiring professional service.
