Forest River FR3 – Furnace Igniter & Control Board Replacement

Forest River FR3 – Furnace Igniter & Control Board Replacement

by

Complete repair guide for the Forest River FR3 – Furnace Igniter & Control Board Replacement. Follow these steps to diagnose and fix the issue yourself.

Parts & Tools You’ll Need

Step 1: Diagnose furnace failure and prepare workspace

Start by confirming the furnace isn’t producing heat or is clicking without igniting—classic signs of igniter electrode or control board failure. Turn off propane at the tank, disconnect the 12V power supply from your RV battery, and allow the furnace to cool for at least 30 minutes. Gather your replacement parts, digital multimeter, and work in a well-ventilated area near the furnace location, typically found in the Forest River FR3’s lower cabinet or utility compartment.

Step 2: Remove furnace access panel and disconnect components

Locate and remove the furnace front access panel by unscrewing 4-6 fasteners (typically Phillips head). Carefully disconnect the wire harness from the furnace circuit board—note the connector positions with a photo for reference. Disconnect the propane feed line at the shutoff valve and the 12V power leads from the blower motor and igniter electrode, which are usually color-coded (red for positive, black for negative).

Step 3: Test igniter electrode and sail switch continuity

Use your digital multimeter set to the continuity or resistance setting (typically 20Ω range) to test the furnace igniter electrode terminals. A reading above 14Ω indicates a failed electrode that must be replaced. Also check the sail switch (air flow switch) by gently depressing its actuator arm—you should hear a click and see continuity reading; if absent, the sail switch requires replacement.

Step 4: Replace igniter electrode and sail switch assembly

Unbolt the igniter electrode from its mounting bracket (typically 2-3 screws) and carefully pull the electrode away from the burner box, noting how the ceramic insulator sits within the ignition chamber. Install the new furnace igniter electrode in reverse order, ensuring the tip sits 1/8 inch from the burner for proper spark distance. Similarly, unscrew and replace the sail switch by disconnecting its wire terminals and positioning the new switch so the actuator arm moves freely when airflow increases.

Step 5: Install replacement furnace circuit board

Remove the old furnace circuit board by unbolting it from the mounting bracket (typically 2-3 fasteners) and carefully disconnecting all wire terminals—take a clear photo before removal to ensure proper reconnection. Install the new circuit board in the same position, ensuring the board sits flat and secure. Reconnect all wire terminals methodically: blower motor leads, igniter electrode leads, sail switch leads, and any safety switch connections, matching wire colors and original positions exactly.

Step 6: Reconnect propane, power, and verify fuel delivery

Reconnect the propane line to the furnace shutoff valve, hand-tightening the fitting first, then using a wrench for a final 1/4 turn—do not over-tighten. Reconnect the 12V power leads to the battery, ensuring positive (red) and negative (black) connections are secure. Turn on propane at the tank and listen for a faint hissing sound, then check all connections with soapy water to confirm there are no bubbles indicating leaks.

Step 7: Test furnace operation and detect propane/CO safely

Set your RV thermostat to heat mode and 5-10 degrees above ambient temperature. You should hear the blower motor start within 30 seconds, followed by the igniter electrode clicking for 5-10 seconds, then flame ignition visible through the viewing port. Once the furnace runs for 2-3 minutes and cycles off properly, test your Propane/CO combo detector alarm to confirm it functions—it should beep once weekly to indicate battery health, and alarm if CO levels exceed 35 ppm or propane is detected.
